ZYVC611 1500V 2000A Vacuum Contactor

Name

Unit

Value

Main circuit

Rated working voltage (Ue)

V

1500

Rated working current (Ie)

A

2000、2600、3200

Rated thermal current（Ith）

Hz

50

Rated frequency (fr)

A

4Ie(AC-4)

Rated making capacity (I)

A

4Ie(AC-4)

Rated breaking capacity (Ic)

kV

4.2

Power frequency withstand voltage

Between phases, phase to earth

kV

10

Control circuit

Rated voltage

V

AC/DC 110/220

Rated power (Ps) Electric holding

VA

≤1600/50

(absorbing/holding)

Auxiliary circuit

Form

3a+3b

Rated value

AC 380V/5A

DC 380V/1A

Control circuit, auxiliary circuit to earth power frequency withstand voltage

kV

2

Rated operating frequency

Long time

Time/h

300

Short time

600

Mechanical endurance

10000 times

30

Electrical endurance

10000 times

10

Mechanical characteristics

Closing time

ms

≤120

Original opening time

ms

≤50

3-phase synchronism

ms

≤3

Closing tripping

ms

≤10

Net weight

kg

85
